ZKT Live 20R Fingerprint Reader Scanner Sensor High-Performance for Computer PC Home and Office

Weight	0.1 kg
Color	Black

ZKT Live 20R Fingerprint Reader Scanner Sensor High-Performance for Computer PC Home and Office

ZKT Live 20R High-Performance Fingerprint Reader

Discover the latest ZKT Live 20R fingerprint scanning technology with our compact and sleek fingerprint device. Designed for durability and top-tier performance, this fingerprint scanner offers a range of applications in security, attendance, encryption, and more. With a premium solid steel surface and exceptional image quality, this device is perfect for businesses and organizations seeking reliable biometric authentication.

Fingerprint Reader Key Features:

• Compact & Stylish: Small, ergonomic design with a solid steel body for durability and a sleek, professional appearance.
• Superior Image Quality: Capture high-definition fingerprint images at a resolution of 500 DPI for excellent clarity and detail.
• Encrypted Image Data: All fingerprint data is encrypted, ensuring privacy and protection.
• Advanced Fingerprint Recognition: Rejects fine, fake, or unclear fingerprints for more accurate and reliable scans.
• Multi-Angle Support: Supports fingerprint rotation for a flexible scanning experience.
• Universal Compatibility: Supports dry, wet, or raw fingers, ensuring accuracy in various conditions.
• Fast & Efficient: With a rapid capture speed of <0.5 seconds, this device enhances user experience and workflow.
• Developer-Friendly: It comes with a free SDK for easy integration into your systems. Supports languages like C++, VB, Delphi, and more.

Applications:

• Social Security & Public Security
• Attendance Systems
• Fingerprint Encryption
• Embedded Applications
• Employee Access Control
• Security Monitoring

ZKT Live 20R Fingerprint Reader Specifications:

• Fingerprint sensor: ZK Optical Sensor with strengthened film
• Resolution: 500DPI/256 grayscale(8-bit)
• Scan size: 15.24*20.32mm(FAP20)
• Image size: 300*400
• Interface: USB1.1, compatible with USB1.0,1.1,2.0
• Registration speed: <0.5 sec
• Registration angle: 360°C
• Operating Temperature: -20°C – 50° C
• Operating Humidity: 0-90%
• Operating System: WINDOWS7/8/10/XP/VISTA(32/64BIT) linux(32/64bit)/android
• USB cable length: 180 CM
• Dimension (L*W*H): 124.5mm*102mm*34mm
• Power Supply: 5.0V +/- 0.25V ( USB interface power)
• Current: Capture fingerprint: max 250 mA
• Idle mode: max 25 mA
• Suspend mode: <0.5 mA
• Size:49*49*18mm(L*W*H)

Fingerprint Reader price in Pakistan only at Playtech.pk

• Fingerprint Sensor: Optical sensor with film enhancement for better image clarity
• Resolution: 500 DPI, 256 gray scale (8-bit) for clear, detailed fingerprint images
• Scan Area: 15.24mm x 20.32mm (FAP20 standard)
• Image Size: 300×400 pixels
• Interface: USB 1.1, backward compatible with USB 1.0, 1.1, and 2.0
• Scan Speed: Fast fingerprint capture in less than 0.5 seconds
• Rotation Angle: 360° rotation for flexible scanning
• Operating Temperature: -20°C to 50°C for reliable performance in varied environments
• Operating Humidity: 0-90% for consistent performance in different climates
• Operating Systems Supported: Windows (7/8/10/XP/Vista), Linux (32/64-bit), Android, iOS
• USB Cable Length: 180 cm for extended reach
• Power Supply: 5V ±0.25V via USB interface
• Current Consumption:
• Fingerprint Capture: Max 250mA
• Idle Mode: Max 25mA
• Suspension Mode: <0.5mA
• Dimensions: 124.5mm x 102mm x 34mm (device size), 49mm x 49mm x 18mm (sensor size)
