ASUS TUF GAMING B660M-PLUS WIFI D4

Intel® B660 (LGA 1700) mATX motherboard, 10+1 DrMOS Power stages , PCIe 5.0 support, DDR4 5333 (OC), Dual PCIe 4.0 M.2 Slots with Flexible Heatsink, Intel® Wi-Fi 6, Realtek 2.5Gb Ethernet, Rear USB 3.2 Gen 2×2 Type-C®, Front USB 3.2 Gen 1 Type-C®, Aura Sync, Two-way AI Noise Cancelation

Durable. Stable. Reliable.

ASUS TUF GAMING B660M-PLUS WIFI D4 takes all the essential elements of the latest Intel® processors and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard offers rock-solid and stable performance for marathon gaming. Aesthetically, TUF GAMING B660M-PLUS WIFI D4 sports the new TUF Gaming logo and incorporates simple geometric design elements to reflect the dependability and stability that defines the TUF Gaming series.

• HDMI®

• DisplayPort

• 2 x USB 3.2 Gen2

• 2 x USB 2.0

• 1 x USB 3.2 Gen 2×2 Type-C®

• 1 x USB 3.2 Gen1

• 2 x USB 3.2 Gen2

• 2.5G Ethernet

• Intel® Wi-Fi 6

• 7.1-ch Audio

• 1 x PCIe 5.0 x16 (CPU)1 x PCIe 3.0 x16 (PCH, at x4 mode)– ASUS SafeSlot

• Realtek® 7.1-ch Audio CODECExclusive DTS Audio Processing– Audio Shielding– Rear optical S/PDIF out port– Premium audio capacitors– Dedicated audio P.C.B layers

• ProCool Connectors

• 3 x Addressable Gen 2 RGB headers1 x RGB Strip header

• DrMOS

• AURA Sync

• DDR4 5333 (OC)ASUS OptiMem II

• Intel® Socket LGA1700 for 12th Gen Intel® Core™,Pentium® Gold and Celeron® Processors

• 1 x Front USB 3.2 Gen 1 header

• 1 x Front USB 3.2 Gen 1 Type-C® port

• 2 x M.2 2280 PCIe 4.0 x4 mode

• 4 x SATA 3.0 Ports

• Intel® B660 Chipset

• 2 x Front USB 2.0 headers

• 1 x Thunderbolt header

•

  Power Design

•

  Cooling

•

  Memory & Storage

•

  Connectivity

Power Design

• Driver and MOSFET

• Multilayer PCB

• Power Connector

• System Stability

• Controller

DrMOS

The onboard VRMs feature 10+1 DrMOS power stages that combine high-side and low-side MOSFETs and drivers into a single package, delivering the power and efficiency that 12th Gen Intel Core processors demand.

TUF Gaming Alliance

TUF Protection

Easy Configuration

Build with Confidence

TUF GAMING Alliance is a collaboration between ASUS and trusted PC component brands to ensure compatibility across a wide range of parts, such as PC cases, power supplies, CPU coolers, memory kits and more. With new partnerships and components being added regularly, the TUF Gaming Alliance will continue to grow even stronger.Learn More

Networking

Two-Way AI NoiseCancelation

Gaming Audio

Aura Sync RGB Lighting

Networking

• Intel® WiFi 6

• 2.5 Gb Ethernet

Intel®WiFi 6

The Intel® WiFi 6 module is compatible with the 802.11ax standard and pushes theoretical peak bandwidth up to an incredible 2.4 Gbps. Perhaps more importantly for power users, it's optimized for more efficient operation on crowded networks with a lot of competing traffic. Pair your motherboard with ASUS WiFi 6 routers to fully experience the networking potential of WiFi 6.

MyASUS

MyASUS offers a variety of support features to help you contact customer service, troubleshoot issues and optimize product performance. You can also use MyASUS to enable the WiFi SmartConnect function to automatically connect to the wireless router with the best signal.

• Intel® LGA 1700 socket: Ready for 12th Gen Intel® processors


• Enhanced power solution: 10+1 DrMOS power stages, six-layer P.C.B, 8+4 ProCool sockets, military-grade TUF components and Digi+ VRM for maximum durability


• Comprehensive cooling: Enlarged VRM heatsink, Stack Cool 3+, Flexible M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+


• Latest connectivity: PCIe 5.0 slot, PCIe 4.0 M.2 slots, rear USB 3.2 Gen 2x2 Type-C®, front panel header for USB 3.2 Gen 1 Type-C® and Thunderbolt 4™ support


• Made for online gaming: Intel® WiFi 6, Realtek 2.5Gb Ethernet, TUF LANGuard


• Two-way AI Noise-Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences
